Tamiya Paint Database – US Aircraft colours, WWII

The Tamiya Paint Database was created as a way to demonstrate the Microsoft FrontPage Access Database Wizard back in the spring of 2000. Originally, anyone could add formulas to the database, and for a while, all was good. Sadly, much time was later required to weed out false entries, and after a while, the DB was taken down. Now it has been restored and more mixes have been added.

While we make every effort to ensure the accuracy of the mixes listed, we cannot test them all. That said, we recommend that you test your own small sample before making a batch large enough to paint a 1/24 scale aircraft. If you do find an error in a formula, please contact us.

Army-Navy Aeronautical (ANA) Color

ANA 601 Insignia White   XF-2 Flat White – 10 parts
XF-55 Deck Tan- 1 parts
ANA 602 Light Gray   XF-19 Sky Grey- 2 parts
XF-2 Flat White – 1 parts
ANA 603 Sea Gray   XF-18 Medium Blue- 3 parts
XF-2 Flat White – 1 parts
ANA 606 Semi-Gloss Sea Blue   XF-17 Sea Blue -6 parts
XF-8 Flat Blue -6 parts
XF-53 Neutral Grey – 1 part
Followed by a coat of clear semi gloss
ANA 607 Non Specular Sea Blue   XF-17 Sea Blue -5 parts
XF-8 Flat Blue -3 parts
XF-53 Flat White – 2 parts
ANA 608 Intermediate Blue   XF-18 Medium Blue- 5 parts
XF-2 Flat White – 4 parts
ANA 609 Azure Blue X-16 Purple – 1 part
XF-2 Flat White -2 parts
ANA 610 Sky   XF-21 Sky – 3 parts
X-2 White- 1 part
ANA 611 Interior Green   XF-3 – Flat Yellow – 1 part
XF-5 – Flat Green – 1 part
ANA 612 Medium Green   XF-13 J.A. Green – 1 part
XF-5 Flat Green – 1 part
XF-21 Sky – 1 part
ANA 613 Olive Drab   XF-62 Olive Drab
ANA 620 Light Gull Gray   XF-19 Sky Grey -1 parts
XF-2 Flat White – 1 part
ANA 621 Dark Gull Gray   XF-24 Dark Grey – 11 parts
XF-20 Medium Grey – 9 parts



Quartermaster (QM) 3-1 Color (Pre-War)

AAF Neutral Gray   XF-53 Neutral Gray



Interior Colors

Salmon Primer   XF-10 Flat Brown – 2 parts
XF-2 Flat White – 2 parts
XF-4 Flat Yellow – 1 part
XF-7 Flat Red – 1 part
Dark Interior Green   XF-5 Flat Green – 2 parts
XF-8 Flat Blue – 1 part

This Post Has 3 Comments

  1. Rafael Gonzales

    Oh my God what a wonderful gift I was waiting for some new paints some I had questions about but you have opened my eyes I can’t believe what I’m saying new paints and to me and how to mix them I am a fan of tumors paint ever since I first try them but they’re not enough colors for them and yet give me more colors that I want and I need those colors very lovely thank you whoever done this thank you very much we have a happy and blessed day and may all your wishes come through thank you

  2. Rafael Gonzales

    When I’m in a jam I’m trying to find a color and I’ll go back to this and it refreshes my mind and it helps me a lot to remember the colors I need to use this is great I love this practice on that you have a nice day

  3. David Hansen

    One thing i’ve been doing, is substituting Tamiya White Surface Primer, decanted from the spray can, in lieu of the XF-2 white.
    So far, there has been no problem in mixing this with Tamiya acrylics.
    In addition, since the white is a primer, it wet sands beautifully.
    I thin all my acrylics and lacquers with Mr Leveling Thinner.
